- Electrical data
Ratings per IEC/EN
Ratings per : EN 60664
Nominal voltage (II/2): 450 V
Rated surge voltage (II/2): 4 kV
Rated current: 32 A
Legend (ratings): (II / 2) ≙ Overvoltage category II / Pollution degree 2
Ratings per UL
Approvals per: UL 486C
Rated voltage UL (Use Group C): 600 V
Rated current UL (Use Group C): 20 A
- Connection data
Connection technology: CAGE CLAMP®
Actuation type: Lever
Connectable conductor materials: Copper
Nominal cross-section: 4 mm²
Solid conductor: 0.2 … 4 mm² / 24 … 12 AWG
Stranded conductor: 0.2 … 4 mm² / 24 … 12 AWG
Fine-stranded conductor: 0.14 … 4 mm² / 24 … 12 AWG
Strip length: 11 mm / 0.43 inch
Total number of connection points: 3
Total number of potentials: 1
Wiring type: Side-entry wiring
- Material data
Color: transparent
Flammability class per UL94: V2
Fire load: 0.048 MJ
Color of actuator: orange
Weight: 2.5 g
- Environmental requirements
Surrounding air temperature (operation): 85 °C
Continuous operating temperature: 105 °C
Temperature marking per EN 60998: T85
